Version: V2.0 (upgraded from V1.0)
Effective Date: April 24, 2025
- ① Appearance/Structure
- ② Function
- ③ Software
- ④ Components
Detailed Upgrade Content:
| Appearance/Structure Improvements | |
|
Shape Optimization: Double straight → L-shaped sound guide tube |
Noise Elimination: Solves "buzzing" from cavity resonance |
| Software Improvements | |
|
EQ Adjustment: Low frequency attenuation 3dB |
Vocal Enhancement: Improved dialogue clarity Comfort: Reduced bass pressure |
July 10, 2024 V1.0 Specifications:
| Product Color | Matte Black Front/Rear | Brown Sides |
| Bluetooth | 5.0 |
| Power | RMS 100W |
| Signal-to-Noise Ratio | ≥85dB |
| Distortion | <1% |
| Frequency Response | 35Hz-20kHz |
| Power Input | 24V 2A |
| Audio Inputs | Bluetooth+Optical+ARC+RCA+USB |
| Audio Output | SUB |
| Speakers | 5.25" Mid-woofer: 4Ω 30W*2 3.5" Dome Tweeter: 6Ω/10W*2 |
| Status Indicator | RGB/Tricolor LED |
| Control Methods | IR Remote/Buttons/Knob |
| Sound Modes | Music/Cinema/Dialogue |
| Main Unit Dimensions | 190×227×310mm (L×W×H) |
| Sub Unit Dimensions | 190×227×310mm (L×W×H) |
| Materials | Main: MDF+ABS+Net | Sub: MDF+ABS+Net |
